Spoke Type Load Cell 5T–50T Compression Force Sensor | High Precision Alloy Steel Load Cell for Industrial Weighing Systems & Heavy Duty Scales
In stock
Original price was: 390,00 €.269,00 €Current price is: 269,00 €.
| Weight | 6 oz |
|---|---|
| Dimensions | 5 in |
| Brand Name | Unbranded |
| High-concerned chemical | None |
| Output | Analog Sensor |
| Theory | Inductance Sensor |
| Type | vibration sensor |
| is_customized | Yes |
| Use | Pressure Sensor |
| Material | Metal |
| Rated load | 5T 10T 20T 30T 50T |
| Output sensitivity | 1.0-2.0±0.05%mV/V |
| Zero output | ±2%F.S. |
| Nonlinearity | ±0.05%F.S. |
| hysteresis | ±0.05%F.S. |
| repeatability | ±0.05%F.S. |
| Temperature sensitivity drift | ±0.03%F.S./10℃ |
| Zero temperature drift | ±0.03%F.S./10℃ |
| Response frequency | 10kHz |
| Input Impedance | 735 ± 35 |
| Output Impedance | 700 ± 30 |
| Excitation voltage | 5-10v |
| Operating temperature range | -20-70℃ |
| Safety overload | 120% |
| Uitimate overioad | ≥2000MΩ/100VDC |
