What is this case study? This page documents a real completed vector art / raster-to-vector conversion order produced by 360 Digitizing Solutions. To protect client privacy, company and brand names have been anonymized. Browse specs, before/after images, and production notes below.
Vector Art Conversion & Spot-Color Separation for Apparel Print
We recently partnered with a local business to convert their raster-based logo into a versatile vector format. The goal was to create print-ready artwork with accurate spot-color separation for various applications, especially apparel.
Final Vector Artwork
Order Specifications
Project Background
Raster images, composed of pixels, lose clarity and become pixelated when enlarged. This issue was critical for the client, as they needed their artwork to maintain crispness and sharp edges across diverse applications, from small labels to large screen-printed shirts.
Beyond simple conversion, the client’s primary need was for production-ready files suitable for screen printing on apparel. This meant not only achieving clean, scalable lines but also ensuring precise spot-color separation, a critical step for accurate color reproduction in print.
They understood that achieving truly clean, scalable vector artwork, especially with accurate color separation, requires expert manual tracing and a deep understanding of print production standards. Automated tools often fall short, leaving jagged lines and inaccurate color breaks.
Even with an existing AI file, it often contained rasterized elements or lacked the proper structure for true vector scalability and spot-color breakdown. Our task was to transform this into a truly versatile and production-ready vector asset.
Vectorization & Color-Separation Process
We paid close attention to optimizing paths and nodes, ensuring the artwork contained the absolute minimum number of points required to maintain fidelity. This meticulous work guarantees exceptionally clean paths and crisp, scalable edges that will never degrade, no matter the output size.
A crucial part of this project was the spot-color separation. We carefully identified each distinct color in the design and separated them onto individual layers, assigning precise Pantone values where applicable. This ensures that the artwork is perfectly prepared for multi-color screen printing, allowing printers to achieve exact color matches and avoid registration issues.
Throughout the vectorization and separation process, our team conducted rigorous quality checks. This included verifying vector integrity, checking for open paths, and confirming that all colors were accurately represented and separated, ensuring the final file was truly print-ready.
- ✓ Clean, scalable vector paths and nodes
- ✓ Crisp, sharp edges at any size
- ✓ Accurate spot-color separation for print
Final Outcome
These new vector assets provide immense versatility. The client can confidently use them for apparel, signage, vehicle wraps, web graphics, and more, knowing the quality will always be impeccable. This conversion empowered them with truly professional-grade graphics for all their marketing and merchandise needs.
Need Print-Ready Vector Art?
We convert any logo or artwork into clean, scalable vector files with proper spot-color separation — ready for screen printing, cutting, and large-format output.
Frequently Asked Questions
Why is vector art conversion important for printing? +
Vector art is crucial for professional printing because it allows images to be scaled infinitely without any loss of quality or clarity, ensuring crisp lines and sharp details at any size.
What is spot-color separation? +
Spot-color separation is the process of breaking down a design into individual layers for each distinct color. This is essential for screen printing and other methods that require precise color matching and registration.
How does 360 Digitizing Solutions ensure quality in vector conversion? +
Our expert artists manually trace and refine every detail, creating clean paths and optimized nodes. This meticulous, human-driven approach ensures superior quality, accurate color separation, and truly print-ready files compared to automated processes.
