Stop Costly Skipped Stitches and Inaccurate Movements

Are you experiencing frustrating skipped steps, inconsistent stitch quality, or sluggish performance from your embroidery machine or CNC equipment? These issues directly impact your production quality, lead to wasted materials, and erode customer confidence. A failing or underpowered stepper motor is often the culprit, causing vibrations and imprecise movements that undermine your work.

Unleash Precision and Reliability in Your Operations

Upgrade to the 360 Digitizing NEMA 17 Stepper Motor 17HS5424-06 and transform your machine‘s performance. This robust 2-phase, 4-lead hybrid stepper motor is engineered to deliver a powerful 85 oz.in (0.6 N·m) holding torque with a 2.5A/phase rated current. Its precise 1.8° step angle ensures exceptionally smooth and accurate angular movements, critical for intricate embroidery designs and detailed CNC work. Designed for stability and durability, the 17HS5424-06 minimizes vibration and heat buildup, extending the life of your equipment and ensuring consistent, high-quality output every time.

Built for Demanding Embroidery and Motion Control Applications

The 17HS5424-06 NEMA 17 Stepper Motor is a versatile powerhouse, ideal for a wide range of precision motion control tasks where accuracy and reliability are paramount. Leverage its consistent performance for:

• Embroidery Machines: Tajima, Barudan, Brother PR Series, Happy, Ricoma, SWF Embroidery Machines
• CNC Applications: CNC Routers, CNC Mills, CNC Lathes, CNC Plasma Cutters, CNC Foam Cutters
• 3D Printing: Enhancing precision and speed in 3D printers
• Automation Equipment: Pick-n-place machines, Dispenser machines, Automated systems
• Laser Systems: Laser Engravers, Laser Cutters, Laser equipment
• Other Precision Devices: Vinyl Sign Cutters, Carver machines, Stage lighting, Instruments, Scanners, Precision telescope positioning systems, Robots

Technical Specifications

• Model: 17HS5424-06
• Step Angle: 1.8°
• Holding Torque: 85 oz.in (0.6 N·m)
• Rated Current: 2.5A/Phase
• Resistance: 1.1Ω
• Inductance: 2.8mH
• Phase: 2
• Leads: 4 (Bipolar connection)
• Type: HYBRID
• Certification: CE
• Condition: New

Compatible with: Tajima Embroidery Machines, Barudan Embroidery Machines, Brother PR Series, Happy Embroidery Machines, Ricoma Embroidery Machines, SWF Embroidery Machines, CNC Machines, 3D Printers, Automation Equipment, CNC mills, milling machines, CNC lathes, Pick-n-place machines, Laser Engravers, Laser Cutters, Vinyl Sign Cutters, CNC Plasma Cutters, CNC Foam Cutters, Carver machine, Dispenser, Automazation, Stage lighting, instrument, laser equipment, scanner, precision telescope positioning systems, robots.

Important Compatibility Note: While this NEMA 17 Stepper Motor is designed for broad compatibility, we always recommend confirming the specific requirements of your machine model before ordering. Not sure if this motor is the right fit? Contact us with your machine model and we will gladly help confirm compatibility.

Why Trust 360 Digitizing Shop?

At 360 Digitizing Shop, we understand that downtime costs you money. That’s why every NEMA 17 Stepper Motor 17HS5424-06 is rigorously function-tested before shipping, ensuring that defective units never leave our warehouse. We stand by the quality of our parts: if a defective item unexpectedly arrives, your purchase is protected, and you will receive a full refund within 4 days under our buyer protection policy. Invest in reliability and keep your embroidery business running smoothly with parts you can trust.

Frequently Asked Questions

What is the primary function of the NEMA 17 Stepper Motor 17HS5424-06?
This motor provides precise, controlled angular movements crucial for applications like embroidery machines, CNC routers, and 3D printers. It ensures accurate positioning and consistent motion, which is vital for high-quality output.

What machines is the 17HS5424-06 compatible with?
The 17HS5424-06 is compatible with a wide range of equipment including Tajima, Barudan, Brother PR Series, Happy, Ricoma, and SWF embroidery machines, various CNC machines (routers, mills, lathes), 3D printers, and general automation equipment.

How can I confirm if this motor will fit my specific machine?
To ensure a perfect fit, we recommend comparing the technical specifications, especially the NEMA 17 frame size and the motor‘s dimensions, with your machine‘s existing motor or specifications. If you’re unsure, please contact us with your machine‘s make and model, and we’ll help confirm compatibility.

What are the key performance specifications of this motor?
The 17HS5424-06 features a 1.8° step angle, 85 oz.in (0.6 N·m) holding torque, and operates at 2.5A/phase. It is a 2-phase, 4-lead hybrid stepper motor.

What is 360 Digitizing Shop's quality assurance and return policy for this motor?
Every NEMA 17 Stepper Motor 17HS5424-06 is function-tested before shipping to prevent defective units. If a defective item arrives, you are protected by our buyer protection policy, guaranteeing a full refund within 4 days.
